Basic Information
| Main steel frame | H-section steel | Q345 steel 8mm to 10mm |
| Welding | Automatic Submerged Arc Welding | |
| Rust removing | Sand blasting | |
| surface processing | Alkyd Paint or galvanized | |
| High strength bolt | Grade 10.9 | |
| Supporting system | Angle brace | L50x4,Steel Q235,Process and painting |
| Cross bracing | dia.20 round bar,Steel Q235, process and painting | |
| Tie bar | dia.89*3 round pipe,Steel Q235 Process and painting | |
| Batter brace | dia.12 round bar,Steel Q235 process and painting | |
| Ordinary bolt | Galvanized bolt | |
| Roof | Purlin | C160*60*2.5,steel Q235,Painting or galvanized |
| Out-roof panel | Sandwich panel or corrugated steel plate | |
| Transparent skylight | 6mm thick PVC | |
| Accessories | Sealant,self-tapping screw, etc. | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Gutter | Made of steel sheet thickness 0.8mm, or PVC | |
| Rinspout | dia.110 PVC | |
| Wall | Purlin | C160*60*2.5,steel Q235,paint |
| Wall panel | Sandwich panel or corrugated steel plate | |
| Accessories | Sealant,self-tapping screw etc | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Ventilator | unpowered axial-flow ventilator or monitor roof | |
| Door window | Rolling door/sliding door, PVC/alu. alloy window | |
| Crane | With or without crane, ranging from 5 tons to 20 tons |
Drawings & Quotation 1) Customized design is welcomed. 2) In order to give you an exactly quotation and drawings, please let us know length, width, eave height and local weather. We will quote for you promptly. |  |
 | Our Design & Engineering Services for the Steel building ( made of steel frame ) 1 ) Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project . 2 ) Simple design service is free of charge to all clients to ensure customer . If you require more complex engineering of structures such as load baring capacities we can also provide this service requiring designer fee . 3 ) We look forward to delivering exceptional designs and advice for your project . |
Installation supervision and after-sales service
If needed , we will dispatch our professional workers to conduct assembling guide or technical support for you on site .
Feature and application of the standard type of steel building structure
1. Portal frame structure has simple force, clear force transmission path, and fast construction speed. It is widely used in industrial and civil buildings such as industrial, commercial, cultural, and entertainment public facilities.
2.Steel building frame structures are flexible and can form a larger space. It is widely used in the multi-story and high-rise building such as commercial office building, shopping mall, conference center and other buildings.
3. Steel truss structure is using small cross-section tube to form larger cross-section components, which are often used in industrial and civil buildings such as large span roof, bridge, tower, marine oil production platform, etc., with large span or height in the building.
4. The steel grid structure is a high-order statically indeterminate space structure composed of many rods according to certain rules with small space stress, lightweight, high rigidity, and excellent seismic resistance. It can be used as a gymnasium, exhibition hall, petrol station and hangars, etc.
Basic Information
| Main steel frame | H-section steel | Q345 steel 8mm to 10mm |
| Welding | Automatic Submerged Arc Welding | |
| Rust removing | Sand blasting | |
| surface processing | Alkyd Paint or galvanized | |
| High strength bolt | Grade 10.9 | |
| Supporting system | Angle brace | L50x4,Steel Q235,Process and painting |
| Cross bracing | dia.20 round bar,Steel Q235, process and painting | |
| Tie bar | dia.89*3 round pipe,Steel Q235 Process and painting | |
| Batter brace | dia.12 round bar,Steel Q235 process and painting | |
| Ordinary bolt | Galvanized bolt | |
| Roof | Purlin | C160*60*2.5,steel Q235,Painting or galvanized |
| Out-roof panel | Sandwich panel or corrugated steel plate | |
| Transparent skylight | 6mm thick PVC | |
| Accessories | Sealant,self-tapping screw, etc. | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Gutter | Made of steel sheet thickness 0.8mm, or PVC | |
| Rinspout | dia.110 PVC | |
| Wall | Purlin | C160*60*2.5,steel Q235,paint |
| Wall panel | Sandwich panel or corrugated steel plate | |
| Accessories | Sealant,self-tapping screw etc | |
| Edge cover | Made of color steel sheet thickness 0.5mm | |
| Ventilator | unpowered axial-flow ventilator or monitor roof | |
| Door window | Rolling door/sliding door, PVC/alu. alloy window | |
| Crane | With or without crane, ranging from 5 tons to 20 tons |
Drawings & Quotation 1) Customized design is welcomed. 2) In order to give you an exactly quotation and drawings, please let us know length, width, eave height and local weather. We will quote for you promptly. | |
| Our Design & Engineering Services for the Steel building ( made of steel frame ) 1 ) Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project . 2 ) Simple design service is free of charge to all clients to ensure customer . If you require more complex engineering of structures such as load baring capacities we can also provide this service requiring designer fee . 3 ) We look forward to delivering exceptional designs and advice for your project . |
Installation supervision and after-sales service
If needed , we will dispatch our professional workers to conduct assembling guide or technical support for you on site .
Feature and application of the standard type of steel building structure
1. Portal frame structure has simple force, clear force transmission path, and fast construction speed. It is widely used in industrial and civil buildings such as industrial, commercial, cultural, and entertainment public facilities.
2.Steel building frame structures are flexible and can form a larger space. It is widely used in the multi-story and high-rise building such as commercial office building, shopping mall, conference center and other buildings.
3. Steel truss structure is using small cross-section tube to form larger cross-section components, which are often used in industrial and civil buildings such as large span roof, bridge, tower, marine oil production platform, etc., with large span or height in the building.
4. The steel grid structure is a high-order statically indeterminate space structure composed of many rods according to certain rules with small space stress, lightweight, high rigidity, and excellent seismic resistance. It can be used as a gymnasium, exhibition hall, petrol station and hangars, etc.
