Basic Information
| Frame | Steel column | □120x120x2.5 |
| Steel structure beam | C120x50x20x2.0 | |
| Roofng Purlin | C140x50x20x2.0 | |
| Wall purlin | C120x50x20x2.0 | |
| Interior wall perlin | C80*40*20*1.5 | |
| Anchor bolts | M16 | |
| Ordinary bolt | 4.8S,Galvanized | |
| Insolation | Roofing-PU board Or fiber glass board | 100mm，40kg, OR 100mm，60kg, |
| Exterior wall-PU board OR Fiber glass board | 100mm，40kg, OR 100mm，60kg, | |
| Insulation layer | 100mm, fiber glass layer | |
| Interior wall- OSB board | 8*1200*2400mm | |
| inner wall-gypsum board | 9.5*1200*3000mm, | |
| inner wall-cement board | 12*1200*2440mm | |
| wall tiles | 600*600mm |
Technical Parameter of standard prefabricated house
1. Wind resistance: Grade 11(wind speed≤111.5km/h)
2. Earthquake resistance: Grade 7
3. Live load capacity of roofing: 0.5kn/m2
3. External and internal wall heat transmission coefficient: 0.35Kcal/m2hc
4. First floor load capacity: 150 kg/m2
5. Live load of corridor is 2.0kn/ m2
6. Four skilled workers can finish installation of 100sqm in 8 hours for the light steel structure.
7. Most components of the house are recycled, so the shelf life is over 20 years without any building garbage.
8. We can design and produce the house according to customer’s request.
9. We can provide the service of installation, supervision and training by extra.
FAQ
1. What products do you offer?
We focus on prefab labor camp, steel structure, container houses, modular villa etc.
2. What is your payment term?
The payment term are TT and L/C.
3. What is your MOQ (minimum order quantity)?
For the prefab house is 200 square meters and 1X40HQ for container house or small units house.
